Description
Technical Specifications
| Hardware Platform | |
| Model Numer | XEG9608 XEG9612 |
| Switch Properties | |
| Priority Queues | 8 |
| VLAN Table | 4096 |
| MAC-Based VLAN | 512 |
| VLAN ID Range | VID 1 to 4094 |
| Trunk Group | 4 |
| Static IGMP Groups | 128 |
| Dynamic IGMP | 256 |
| Groups MAC Table | 16K |
| Size Packet Buffer | 1.5 MB |
| Size Jumbo Frame | 9216 Byte |
| Ethernet | |
| Â
  Standards |
IEEE 802.3 for 10BASE-T
IEEE 802.3u for 100BASE-T(X) IEEE 802.3ab for 1000BASE-T IEEE 802.3z for 1000BASE-X IEEE 802.3x for Flow Control/ Back pressure control IEEE 802.1d-2004 for Spanning Tree Protocol IEEE 802.1w for Rapid Spanning Tree Protocol IEEE 802.1s for Multiple Spanning Tree Protocol IEEE 802.1q for VLAN Tagging IEEE 802.1p for Class of Service IEEE 8021x for Authentication |
| Â
  Protocols |
IPv4, IPv6, IGMPv1/v2/v3, IGMP Snooping, GARP, GMRP, GVRP, SNMPv1/v2c/ v3, SNMP Inform, ICMP, Telnet, SSH, DHCP Server/Relay/Client, DHCP Option 66/67/82, BootP, RARP, TFTP, NTP Server/Client, SNTP, SMTP, SMTP (Gmail), RMON, HTTP, HTTPS, Syslog, MRP (Manager/ Client), LLDP, IEEE 1588 PTP
V1/V2, IEEE 1588 Hardware-Assisted End-to-End Transparent Clock and Soft- ware-assisted Boundary Clock, 802.1x, EAP, RADIUS, TACACS+, Mirror port, QoS, ACL, Serial Console, U-Ring, STP, RSTP, MSTP, Redundancy Compatible Ring, DHCP Snooping, ARP Spoof Prevention, Dynamic ARP Inspection, MLD, UDLD, IP Source Guard, sFlow |
| Â
Layer-3 Protocols |
Routing: IPv4 Unicast static routing, RIP v1/v2, OSPFv2, BGPv4 Multicast: IGMPv1/v2/v3, DVMRP, PIM-DM, PIM-SM, PIM-SSM
Routing Redundancy: VRRP (Virtual Router Redundancy Protocol) |
| Redundancy | ITU-T G.8032 ERPS, STP, RSTP, MSTP, MRP(Manager/Client), Compatible Ring/Chain, U-Ring |
| Automation Profiles | Modbus/TCP status registers |
| Â
SNMP MIB |
MIB II, IF-MIB, SNMPv2 MIB, BRIDGE-MIB, RMON MIB Group 1,2,3,9, RFC RFC 1157, RFC 1213, RFC 1215, RFC 1493, RFC 1643, RFC 1757, RFC 2011,
RFC 2012, RFC 2013, RFC 2233, RFC 2571, RFC 2742, RFC 2819, RFC 2863, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415 |
| Power | |
| Input Voltage | 24-57 VDC
100~240 VAC for AC series 110~370 VDC for HV Series |
| Input Current (System) | 0.63A @ 24 VDC
0.16A @ 100 VAC for AC series 0.12A @ 110 VDC for HV series |
| Connector | 5-Pin 5.08mm Lockable Terminal Block |
| Reverse Polarity Protection | Yes |
| Interface | ||
| RJ45 Ports | Up to 8×10/100/1000BASE-T(X) auto negotiation speed Up to 4 1000BASE-X SFP slot | |
| Fiber Optics | 2 relay outputs with current carrying capacity of 1A @ 24 VDC Ring Control
|
|
| Â LED Indicators | PWR1, PWR2, Alarm, Run, Ring, Ring Master, RJ-45 Link/Speed, SFP Link, RS232 (RJ45 connector) |
|
| Â Console | Link, RS232 (RJ45 connector) | |
| Â Relay | 2 relay outputs with current carrying capacity of 1A @ 24 VDC | |
| Output DIP | Ring Control | |
| Switches Button | Reset Button | |
| Physical Characteristics | ||
| Housing | IP30 SPCC, Black | |
| Dimension (W x H x D) Weight | housing 77 x 145 x 113 mm |
|
| Installation | 1,000g (AC/HV versions) / 1,200g (other) DIN-Rail , Wall mount (optional kit) |
|
| Environmental Limits | ||
| Operating Temperature | -40°C~85°C (-40°F~185°F) | |
| Storage Temperature | -40°C~85°C (-40°F~185°F) | |
| Ambient Relative Humidity | 5%~95% RH, 55°C (Non-condensing) | |
XEG9600 Series
| XEG9608-2S | 8-Port Layer-3 IEC 61850-3 Gigabit switch with 2 SFP ports, 24~57 VDC power input |
| XEG9608-2S-HV | 8-Port Layer-3 IEC 61850-3 Gigabit switch with 2 SFP ports, 110-370 VDC power input |
| XEG9608-2S-AC | 8-Port Layer-3 IEC 61850-3 Gigabit switch with 2 SFP ports, 100-240 VAC power input |
| XEG9612-4S | 12-Port Layer-3 IEC 61850-3 Gigabit switch with 4 SFP ports, 24~57 VDC power input |
| XEG9612-4S-HV | 12-Port Layer-3 IEC 61850-3 Gigabit switch with 4 SFP ports, 110-370 VDC power input |
| XEG9612-4S-AC | 12-Port Layer-3 IEC 61850-3 Gigabit switch with 4 SFP ports, 100-240 VAC power input |
