Description
Cellular Specification
| Â Module | Industrial grade wireless module |
| Â Frequency | Support for FDD LTE: Band 1/3, Band 2/4/5/13/17/25 (Optional)
Support CDMA 1XRTT/EVDO 800/1900MHz Support the whole network (Optional) : TDD-LTE, FDD-LTE, EVDO, WCDMA, TD-SCDMA, CDMA1X, GPRS/EDGE |
| Power | < 23dBm |
| Sensitivity | <- 93.3dBm |
Wi-Fi Specification
| Frequency | Support IEEE802.11b/g/n |
| Bandwidth | IEEE802.11b/g：54Mbps , IEEE802.11n：150Mbps |
| Security | Support WEP, WPA, WPA2 and other encryption methods, WPS (Optional) |
| Power | 20dBm（11n），24dBm（11g），26dBm（11b） |
| Sensitive | <-72dBm @ 54Mbps |
Hardware System
| CPU | Industrial-grade 32-bit communication processor |
| Flash | 16MB, Extensible to 32MB |
| DDR3 | 128MB |
Interfaces
| WAN | 1 x 10/100M Ethernet （RJ45） , Auto MDI/MDIX, Built-in 1.5KV electromagnetic isolation protection |
| LAN | 4 x 101000M Ethernet （RJ45）, Auto MDI/MDIX, Built-in 1.5KV electromagnetic isolation protection |
| Serial | 1 x RS232(RS422/RS485), Built-in 1.5KV electromagnetic isolation protection Data bit：5, 6, 7, 8
Stop bit：1, 1.5(Optional), 2 Calibration: null, even, odd, SPACE(Optional) and MARK (Optional) Baud rate：2400~115200bits/s |
| Indicators | “PWR”, “SYS”, “WIFI”, “SIM”, “Online”, “Signal Strength” |
| I/O Ports | 6-pin 3.5mm wiring terminal, 2 inputs, 1 output, 1 relay; Controlled by Modbus protocol Input high level: 5 to 30 VDC
Input low level: 0 to 3 VDC Load current: 50mA @ 30VDC Relay load 1A 250V AC/ 30V DC |
| Antennas | Cellular：2 standard SMA female antenna interfaces, characteristic impedance 50 ohms WIFI：1 standard SMA male antenna interfaces, characteristic impedance 50 ohms
GPS: 1 calibrated SMA male antenna interface, characteristic impedance 50 ohms |
| SIM/UIM | Standard drawer type user card interface , Support 1.8V/3V SIM/UIM card, built-in 15KV ESD protection
|
| Power | Terminal power socket |
| Reset Button | 2 bins terminal power socket, built-in power reverse protection and overvoltage protection |
Power supply
| Standard | DC 12V/1.5A |
| range | DC 5 ~36V |
| Consumption | <500mA (12V) |
Physical Properties
| Shell | Metal shell, protection grade IP68 |
| Size | 134.8 x 115.7 x 45mm
(Does not include antenna and mounting parts) |
| weight | 520g |
Others
| Operating Temperature | -35~+75ºC（-31~+167℉） |
| Storage Temperature | -40~+85ºC（-40~+185℉ |
| Relative Humidity | 95% (No condensation) |
| Model | Technology | WAN | LAN | I/O | WIFI | SIM/UIM |
| XWR3450-1M | LTE Cat4 | 1 | 4 | 2DI,1DO | 1 | 1 |
| XWR3450-2M | LTE Cat4 | 1 | 4 | 2DI,1DO | 1 | 2 |
| XWR3450-2MD | LTE Cat4 | 1 | 4 | 2DI,1DO | 1 | 2 Modules |
| XWR3450-2M-EG | LTE Cat4 | 1 | 4 | NO I/O’s | 1 | 2 |
